Range of modular displays

1x3 Straight Systems
System Configuration
width 1160 mm
depth 300 mm
height (without over head light) 2350 mm
height (with over head light) 2450 mm
weight (in kg without case) 10.5 kg
Packaging:nylon case
height 865 mm
diameter 305 mm
Graphics Area
front side: 773 mm x 2332 mm 1 no.
back side: 773 mm x 2332 mm 1 no.
end cap: 587 mm x 2332 mm 2 nos.
Floor Area (meter grid)
2x3 Straight Systems
System Configuration
width 1940 mm
depth 300 mm
height (without over head light) 2350 mm
height (with over head light) 2450 mm
weight (in kg without case) 15 kg
Packaging:nylon case
height 865 mm
diameter 305 mm
Graphics Area
front side: 773 mm x 2332 mm 2 nos.
back side: 773 mm x 2332 mm 2 nos.
end cap: 587 mm x 2332 mm 2 nos.
Floor Area (meter grid)
3x3 Straight Systems
System Configuration
width 2710 mm
depth 300 mm
height (without over head light) 2350 mm
height (with over head light) 2450 mm
weight (in kg without case) 19.5 kg
Packaging:flight case
height 902 mm
width 420 mm
height 415 mm
Graphics Area
front side: 773 mm x 2332 mm 3 nos.
back side: 773 mm x 2332 mm 3 nos.
end cap: 587 mm x 2332 mm 2 nos.
Floor Area (meter grid)
4x3 Straight Systems
System Configuration
width 3480 mm
depth 300 mm
height (without over head light) 2350 mm
height (with over head light) 2450 mm
weight (in kg without case) 24 kg
Packaging:nylon case
height 902 mm
width 420 mm
depth 415 mm
Graphics Area
front side: 773 mm x 2332 mm 4 nos.
back side: 773 mm x 2332 mm 4 nos.
end cap: 587 mm x 2332 mm 2 nos.
Floor Area (meter grid)
2 x 3 concave system
System Configuration
width 1930 mm
depth 480 mm
height (without over head light) 2350 mm
height (with over head light) 2450 mm
weight (in kg without case) 14 kg
Packaging:nylon case
height 865 mm
diameter 305 mm
Graphics Area
front side: 720 mm x 2332 mm 2 nos.
back side: 840 mm x 2332 mm 2 nos.
end cap: 587 mm x 2332 mm 2 nos.
Floor Area (meter grid)
2 x 3 convex system
System Configuration
width 1930 mm
depth 480 mm
height (without over head light) 2350 mm
height (with over head light) 2450 mm
weight (in kg without case) 15.3 kg
Packaging:nylon case
height 865 mm
diameter 305 mm
Graphics Area
front side: 773 mm x 2332 mm 2 nos.
back side: 773 mm x 2332 mm 2 nos.
end cap: 587 mm x 2332 mm 2 nos.
Floor Area (meter grid)
3 x 3 concave system
System Configuration
width 2610 mm
depth 670 mm
height (without over head light) 2350 mm
height (with over head light) 2450 mm
weight (in kg without case) 19 kg
Packaging:flight case
height 902 mm
width 420 mm
height 415 mm
Graphics Area
front side: 720 mm x 2332 mm 3 nos.
back side: 840 mm x 2332 mm 3 nos.
end cap: 587 mm x 2332 mm 2 nos.
Floor Area (meter grid)
3 x 3 convex system
System Configuration
width 2610 mm
depth 670 mm
height (without over head light) 2350 mm
height (with over head light) 2450 mm
weight (in kg without case) 20 kg
Packaging:flight case
height 902 mm
width 420 mm
depth 415 mm
Graphics Area
front side: 720 mm x 2332 mm 3 nos.
back side: 773 mm x 2332 mm 3 nos.
end cap: 587 mm x 2332 mm 2 nos.
Floor Area (meter grid)
4 x 3 concave system
System Configuration
width 3190 mm
depth 930 mm
height (without over head light) 2350 mm
height (with over head light) 2450 mm
weight (in kg without case) 23.5 kg
Packaging:flight case
height 902 mm
width 420 mm
depth 415 mm
Graphics Area
front side: 720 mm x 2332 mm 4 nos.
back side: 840 mm x 2332 mm 3 nos.
end cap: 587 mm x 2332 mm 2 nos.
Floor Area (meter grid)
3 x 3 convex system
System Configuration
width 3190 mm
depth 3190 mm
height (without over head light) 2350 mm
height (with over head light) 2450 mm
weight (in kg without case) 25 kg
Packaging:flight case
height 902 mm
width 420 mm
depth 415 mm
Graphics Area
front side: 720 mm x 2332 mm 4 nos.
back side: 840 mm x 2332 mm 4 nos.
end cap: 587 mm x 2332 mm 2 nos.
Floor Area (meter grid)
3 x 5 circular system
System Configuration
diameter 985 mm
height (without over head light) 2299 mm
height (with over head light) 2399 mm
weight (in kg without case) 18 kg
Packaging:flight case
height 902 mm
width 420 mm
depth 415 mm
Graphics Area
panel: 773 mm x 2276 mm 4 nos.
Floor Area (meter grid)
2 x 5 circular system
System Configuration
width 985 mm
depth 492.5 mm
height (without over head light) 2299 mm
height (with over head light) 2399 mm
weight (in kg without case) 10.5 kg
Packaging:flight case
height 865 mm
diameter 305 mm
Graphics Area
panel: 773 mm x 2276 mm 4 nos.
Floor Area (meter grid)
2 x 5 circular system
System Configuration
width 865 mm
depth 450 mm
height (without over head light) 2299 mm
height (with over head light) 2399 mm
weight (in kg without case) 10 kg
Packaging:flight case
height 865 mm
diameter 305 mm
Graphics Area
panel: 773 mm x 2276 mm 1 no.
end cap: 587 mm x 2332 mm (can be printed or plain vinyl) 2 nos.
Floor Area (meter grid)
Combination Systems
System Configuration
width 4800 mm
depth 900 mm
height (without over head light) 2350 mm
height (with over head light) 2450 mm
weight (in kg without case) 33 kg
Graphics Area
front side: 773 mm x 2332 mm 2 nos.
back side: 720 mm x 2332 mm 4 nos.
end cap: 587 mm x 2332 mm 2 nos.
Floor Area (meter grid)
Combination Systems
System Configuration
width 4800 mm
depth 900 mm
height (without over head light) 2350 mm
height (with over head light) 2450 mm
weight (in kg without case) 35 kg
Graphics Area
panel: 773 mm x 2332 mm 2 nos.
panel: 840 mm x 2332 mm 4 nos.
end cap: 587 mm x 2332 mm 2 nos.
Floor Area (meter grid)
Combination Systems
System Configuration
width 4800 mm
depth 900 mm
height (without over head light) 2350 mm
height (with over head light) 2450 mm
weight (in kg without case) 33 kg
Graphics Area
panel: 773 mm x 2332 mm 2 nos.
panel: 840 mm x 2332 mm 4 nos.
end cap: 587 mm x 2332 mm 2 nos.
Floor Area (meter grid)
Combination Systems
System Configuration
width 4000 mm
depth 1100 mm
height (without over head light) 2350 mm
height (with over head light) 2450 mm
weight (in kg without case) 30 kg
Graphics Area
panel: 773 mm x 2332 mm 2 nos.
panel: 840 mm x 2332 mm 3 nos.
end cap: 587 mm x 2332 mm 2 nos.
Floor Area (meter grid)
Combination Systems
System Configuration
width 3190 mm
depth 930 mm
height (without over head light) 2350 mm
height (with over head light) 2450 mm
weight (in kg without case) 23 kg
Graphics Area
panel: 773 mm x 3105 mm 2 nos.
panel: 1440 mm x 773 mm 1 no.
end cap: 587 mm x 3105 mm 2 nos.
Floor Area (meter grid)
Combination Systems
System Configuration
width 3190 mm
depth 930 mm
height (without over head light) 2350 mm
height (with over head light) 2450 mm
weight (in kg without case) 24 kg
Graphics Area
panel: 853 mm x 3105 mm 2 nos.
panel: 1680 mm x 733 mm 1 no.
end cap: 587 mm x 3105 mm 2 nos.
Floor Area (meter grid)
45° connection
System Configuration
width 2280 mm
depth 690 mm
height (without over head light) 2350 mm
height (with over head light) 2450 mm
weight (in kg without case) 17.5 kg
Graphics Area
panel: 773 mm x 2332 mm 2 nos.
panel: 290 mm x 2332 mm 1 no.
end cap: 587 mm x 2332 mm 2 nos.
Floor Area (meter grid)
90° connection
System Configuration
width 1980 mm
depth 1025 mm
height (without over head light) 2350 mm
height (with over head light) 2450 mm
weight (in kg without case) 17.7 kg
Graphics Area
panel: 773 mm x 2332 mm 2 nos.
panel: 290 mm x 2332 mm 1 no.
end cap: 587 mm x 2332 mm 2 nos.
Floor Area (meter grid)
s connection
System Configuration
width 2565 mm
depth 700 mm
height (without over head light) 2350 mm
height (with over head light) 2450 mm
weight (in kg without case) 18 kg
Graphics Area
panel: 773 mm x 2332 mm 3 nos.
end cap: 587 mm x 2332 mm 2 nos.
Floor Area (meter grid)
hinged connection
System Configuration
diameter 2195 mm
height (without over head light) 2350 mm
height (with over head light) 2450 mm
weight (in kg without case) 35.5 kg
Graphics Area
panel: 773 mm x 2332 mm 2 nos.
end cap: 587 mm x 2332 mm 2 nos.
Floor Area (meter grid)
Horizontal System as Podium
Horizontal System As Podium
height 810 mm
width 2650 mm
depth 2650 mm
weight (in kg without case) 23 kg
Product Display Area (meter square)
area on single system 0.7
Windows for Product Display
Horizontal System As Podium
height 773 mm
width 773 mm
depth 300 mm
partitions: single/double
Product Display Area (meter square)
area on single system 0.232
endcap area on single partition 0.05
Windows for Product Display
Horizontal System As Podium
height 450 mm
width 773 mm
depth 272 mm
partitions: single
Product Display Area (meter square)
area on single system 0.18
Windows for Product Display
Horizontal System As Podium
diameter 1085 mm
height 930 mm
weight (in kg without case) 13.4 kg
Product Display Area (meter square)
area on single system 0.75
Cashew Shaped Counter
System Configuration
height 820 mm
width 1237 mm
depth 400 mm
weight (in kg without case) 9 kg
Graphics Area
panel: 840 mm x 779 mm 1 no.
end cap: 600 mm x 600 mm 2 nos.
Floor Area (meter grid)
Quarter Circular Counter
System Configuration
height 930 mm
width 900 mm
depth 475 mm
weight (in kg without case) 6 kg
Graphics Area
panel: 773 mm x 905 mm 1 no.
end cap: 587 mm x 905 mm 2 nos.
Floor Area (meter grid)
Semi Circular Counter
System Configuration
height 930 mm
width 1085 mm
depth 580 mm
weight (in kg without case) 7 kg
Graphics Area
panel: 773 mm x 905 mm 1 no.
Floor Area (meter grid)
Circular Counter
System Configuration
diameter 1085 mm
height 820 mm
weight (in kg without case) 13.4 kg
Graphics Area
panel: 773 mm x 905 mm 4 nos.
Floor Area (meter grid)
Flatframe Display with Header
System Configuration
height 2126 mm
width 1830 mm
weight (in kg without case) 22 kg
Graphics Area
panel: 570 mm x 870 mm 8 nos.
panel: 570 mm x 257 mm 2 nos.
Floor Area (meter grid)
Flatframe Display with Header and Podium
System Configuration
height 2126 mm
width 1525 mm
weight (in kg without case) 20 kg
Graphics Area
panel: 570 mm x 870 mm 7 nos.
panel: 570 mm x 257 mm 1 no.
Floor Area (meter grid)
Rectangular Display with Triangular Podiums
System Configuration
height 1826 mm
width 1525 mm
weight (in kg without case) 12 kg
Packaging: custom built nylon case
Graphics Area
panel: 570 mm x 870 mm 10 nos.
Floor Area (meter grid)
Triangular Podium with Product Display Racks
System Configuration
height 1826 mm
width 610 mm
weight (in kg without case) 7.5 kg
Packaging: custom built nylon case
Graphics Area
panel: 570 mm x 870 mm 3 nos.
panel: 570 mm x 290 mm 3 nos.
Floor Area (meter grid)
Square Podium with Product Display Racks
System Configuration
height 1826 mm
width 610 mm
weight (in kg without case) 10.2 kg
Packaging: custom built nylon case
Graphics Area
panel: 570 mm x 870 mm 4 nos.
panel: 570 mm x 290 mm 4 nos.
Floor Area (meter grid)
Hexoganal Podium
Hexoganal Podium
height 1067 mm
width 1505 mm
weight (in kg without case) 8.9 kg
Packaging: custom built nylon case
Graphics Area
panel: 720 mm x 1024 mm 6 nos.
Floor Area (meter grid)
Rectangular Podium
Hexoganal Podium
height 1067 mm
width 762 mm
weight (in kg without case) 16.1 kg
Packaging: custom built nylon case
Graphics Area
panel: 720 mm x 1024 mm 4 nos.
Floor Area (meter grid)
2 feet x 1 feet Standard Frames
System Configuration
height 300 mm
width 610 mm
depth 20 mm
weight (with sunboard) 0.9 kg
Graphics Area
front: 570 mm x 257 mm 1 no.
back: 570 mm x 257 mm 1 no.
2.5 feet x 1 feet Standard Frames
System Configuration
height 300 mm
width 762 mm
depth 20 mm
weight (with sunboard) 1.0 kg
Graphics Area
front: 720 mm x 257 mm 1 no.
back: 720 mm x 257 mm 1 no.
2 feet x 3 feet Standard Frames
System Configuration
height 913 mm
width 610 mm
depth 20 mm
weight (with sunboard) 2.5 kg
Graphics Area
front: 570 mm x 870 mm 1 no.
back: 570 mm x 870 mm 1 no.
2.5 feet x 3.5 feet Standard Frames
System Configuration
height 1067 mm
width 762 mm
depth 20 mm
weight (with sunboard) 3.0 kg
Graphics Area
front: 720 mm x 1024 mm 1 no.
back: 720 mm x 1024 mm 1 no.
Counter 1
System Configuration
width 838 mm
depth 560 mm
height 955 mm
weight (in sunboard) 9.5 kg
Packaging: custom built nylon case
Graphics Area
panel: 712 mm x 800 mm 1 no.
Floor Area (meter grid)
Counter 2
System Configuration
width 1000 mm
depth 350 mm
height 955 mm
weight (in sunboard) 8 kg
Packaging: custom built nylon case
Graphics Area
panel: 570 mm x 870 mm 1 no.
panel: 257 mm x 870 mm 2 nos.
Floor Area (meter grid)
Banner Stand 59" x 72"
System Configuration
width 1498 mm
depth 350 mm
height 1875 mm
weight (in kg with case) 7.5 kg
Graphics Area
banner: 1398 mm x 1829 mm 1 no.
Floor Area (meter grid)
Banner Stand 33" x 78"
System Configuration
width 940 mm
depth 350 mm
height 2025 mm
weight (in kg with case) 6.5 kg
Packaging: nylon case
width 838 mm
depth 178 mm
height 102 mm
Graphics Area
banner: 838 mm x 1975 mm 1 no.
Floor Area (meter grid)
Banner Stand 30" x 72"
System Configuration
width 860 mm
depth 350 mm
height 1875 mm
weight (in kg with case) 5 kg
Packaging: nylon case
width 889 mm
depth 178 mm
height 102 mm
Graphics Area
banner: 762mm x 1829 mm 1 no.
Floor Area (meter grid)
Banner Stand 23" x 36"
System Configuration
width 680 mm
depth 225 mm
height 1425 mm
weight (in kg with case) 3.5 kg
Packaging: nylon case
width 660 mm
depth 178 mm
height 102 mm
Graphics Area
banner: 584 mm x 1370 mm 1 no.
Floor Area (meter grid)
Modular Display Fixtures
  • specially designed aluminum extruded profiles
  • variety of connectors to create shapes
  • insertable as well as magnetically mounted graphics
  • suitable for wall & ceilings
Modular Display Fixtures
  • modular platforms.
  • quick & easy to set up.
  • variety of floor finishes.
  • tiled finish with possibility of backlit floors.
Brochure Stands
Customized Dispensers
